AF 71 G with metal scraper
The AF 71 G automatic scraper filter is the smallest self-cleaning model produced by Filtration Group.
Its ultra-compact design facilitates on-board installation, both during the design and retrofit phases.
Areas of application
Food
Mechanic
Chemical
naval
Cosmetic
industrial
Applications
Filtration and homogenization of liquids and pastes of various densities and viscosities.
- Two sizes available – AF 711 and AF 713.
- Ideal for solid-liquid concentrations up to 5,000 mg/l.
- Suitable for installation on both new and older systems.
- Automatic operation with timed operation or with differential pressure control.
- Manual version available.
- Installed power 0.06 kW.
- Filtration range 30 – 2,000 µm.
- Maximum flow rate up to 130 l/min.
- Compact design.
- Low operating costs, reduced installed power, and no consumable filter media.
- Cleaning in real time, without interrupting flow.
- Long life thanks to solid construction and high-quality materials.
- The filter can operate both on the suction side, to protect the pump, or on the pressure side.
- The filter’s clogging status is monitored by a differential pressure switch.
- The filter element can be restored using an ultrasonic bath or manual cleaning with a high-pressure jet.
